Name: UL20267 Signal Round Cable, 3M Alternative Cable, Round Flat Jacketed Shielded Cable
Brand: Luoyang Yilaite Automotive Technology Co., Ltd.
SKU: UL20267 Signal Round Cable, 3M Alternative Cable, Round Flat Jacketed Shielded Cable
Availability: InStock
Rating: 5 (1 reviews)

No.UL20267 Signal Round Cable, 3M Alternative Cable, Round Flat Jacketed Shielded Cable

UL20267 Signal Round Cable, 3M Alternative Cable, Round Flat Jacketed Shielded Cable

GET A QUOTE

Add to Quote List View Quote List

Description

UL20267 Signal Round Cable, 3M Alternative Cable, Round Flat Jacketed Shielded Cable Specification

I. Electrical Performance

Rated Voltage: Ranging from 30V AC/DC (for low - voltage applications) to 300V (for high - insulation models).

Current Capacity: 0.5A to 5A (depending on the conductor cross - sectional area).

Contact Resistance: ≤50mΩ (for connector contacts).

II. Mechanical Performance

Conductor Material: Tinned copper or bare copper, with wire diameter ranging from 0.05mm² to 0.5mm².

Insulation Material: Polyester (PET), Polyimide (PI) or flame - retardant PVC.

Pitch: 0.5mm, 1.0mm, 1.25mm, etc. (common specifications for FFC).

III. Environmental Adaptability

Operating Temperature: - 40℃ to +105℃ (standard type).

Flame Retardant Rating: UL 94 V - 0 or VTM - 0 (for flame - retardant materials).

Protection Level: IP67/IP68 (some circular connectors are waterproof and dustproof).

IV. Structural Characteristics

Shielding Type: Optional aluminum foil shielding or braided shielding (for EMI protection).

Cable Outer Diameter: 1.5mm to 10mm (common range for circular cables).

V. General Electrical Parameters

Complies with UL 758 (Cables for Equipment Wiring) and UL 1581 (Test Standards for Wires and Cables).

VI. Typical Application Scenarios

Consumer Electronics: Internal connections in printers and scanners.

Industrial Equipment: Signal transmission for robots and sensors.

Automotive Electronics: In - vehicle displays and control modules (complies with ISO 6722 standard).

Medical Equipment: For high - reliability flexible connection requirements.
